Benewake TFS20-L Miniaturized Single-Point LiDAR Sensor, (Range: 0.2~20m)

The Benewake TFS20-L Miniaturized Single-Point LiDAR Sensor, (Range: 0.2~20m) is a miniaturized single-point LiDAR module that measures distance using direct time-of-flight (dToF). pulsed laser signal of Benewake TFS20-L Miniaturized Single-Point LiDAR emitted, reflected by the target, and detected by a high-sensitivity SPAD sensor, allowing the module to calculate the distance based on the time difference between the transmitted and received signals based on the speed of light.

Application :

1. Level Detection  :Level Detection, Volume Detection ,Liquid Level Detection ,Space & People Flow Detection
2. Robot : Pallet Transport Robot Obstacle Avoidance , Crane Positioning / Obstacle Avoidance, Robot Fall Prevention & Obstacle Avoidance truck oration
3. IoT : Auxiliary Focus ,Smart Trigger ,Security Warning
4. Smart Parking : Highway Key Area Monitoring ,V2X / Holographic Intersection / Traffic Light Control , Meli train collision avoidance system ,Smart Civil Aviation
5. IoT : Auxiliary Focus, Smart Trigger ,Security warning

Feature :

1. The TFS20-L is a miniaturized single-point LiDAR module that measures distance using direct time-of-flight (dToF). A pulsed laser signal is emitted, reflected by the target, and detected by a high-sensitivity SPAD sensor, allowing the module to calculate the distance based on the time difference between the transmitted and received signals
2. Compact, lightweight, and accurate with long-range measurement, this device performs exceptionally well even in strong ambient light, making it ideal for miniature dToF applications.”
3. The TFS20-L operates on a 3.3V supply with built-in temperature compensation, supporting I²C and UART interfaces for easy integration. Its compact design suits applications like consumer drones, service robots, and IoT.

Package include :

1 x Benewake TFS20-L Miniaturized Single-Point LiDAR Sensor, (Range: 0.2~20m)
