| Hardware Parameter |
| Working voltage | 12V ~ 16V |
| Input voltage | 3S ~ 6S |
| Output voltage | 5V (connect with PWM) |
| Dynamic current | 620~850mA @ 12V |
| Idle current | 620mA @ 12V |
| Working environment temp. | -20℃ ~ +60℃ |
| Output | micro HDMI(FHD output 1080P 30fps) / IP(1080P/720p 25/30fps) / Skyport |
| Local-storage | TF card (Up to 128G, class 10, FAT32 or ex FAT format) |
| Photo storage format | JPG(1920*1080) |
| Video storage format | MP4 (1080P/720P 25fps/30fps) |
| Control method | PWM / TTL / S.BUS/ TCP(IP output version /Skyport) |
| Gimbal Spec |
| Mechanical Range | Pitch/Tilt: -75°～120°, Roll: ±60°, Yaw/Pan: ±300° / ±360°*N (IP output version/Skyport) |
| Controllable Range | Pitch/Tilt: -45°～90°, Yaw/Pan: ±290° / ±360°*N (IP output version/Skyport) |
| Vibration angle | Pitch/Roll: ±0.02°, Yaw：±0.02° |
| One-key to center | √ |
| EO Camera Spec |
| Imager Sensor | 1/3-type CMOS(Progressive Scan) |
| Picture quality | Full HD 1080 (1920*1080) |
| Effective pixel | 4.08MP |
| Lens optical zoom | 10x, F=3.2~33.6mm |
| Digital zoom | 16x |
| Min object distance | 10mm(wide end) to 800mm(tele end) |
| Horizontal viewing angle | 58.2°(wide end) ~ 6.9°(tele end) |
| Sync system | Internal |
| S/N ratio | more than 50dB |
| Min illumination | 0.5 lx (1/30s, F1.8, 50%) |
| Gain | Auto / Manual |
| White balance | ATW1 (Narrow), ATW2 (Wide), single touch, manual (B, R) |
| Shutter speed | 1/1s to 1/10,000s |
| Backlight compensation | Yes |
| Aperture control | 16 steps |
| OSD | Yes |
| IR Thermal imager spec |
| Lens size | 19mm |
| Horizontal FOV | 32° |
| Vertical FOV | 24° |
| Diagonal FOV | 39.4° |
| Detective Distance (Man: 1.8×0.5m) | 559 meters |
| Recognize Distance (Man: 1.8×0.5m) | 140 meters |
| Verified Distance (Man: 1.8×0.5m) | 70 meters |
| Detective Distance (Car: 4.2×1.8m) | 1714 meters |
| Recognize Distance (Car: 4.2×1.8m) | 428 meters |
| Verified Distance (Car: 4.2×1.8m) | 214 meters |
| Working mode | Uncooled long wave (8μm~14μm) thermal imager |
| Detector pixel | 640*480 |
| Pixel size | 17μm |
| Focusing method | Athermal prime lens |
| Emissivity correction | 0.01~1 |
| NETD | ≤50mK (@25℃) |
| MRTD | ≤650mK (@characteristic frequency) |
| Image enhancement | Auto adjust image brightness and contrast ratio |
| Color palette | White, iron red, pseudo color |
| Auto Non-uniform correction | Yes (no shutter) |
| Digital zoom | 1x~12x |
| Sync correct time | Yes |
| Thermometry type | Not Support |
| Detective range | -30 ℃ ~ 300 ℃ (within 8μm~14μm) |
| EO / IR Camera Object Tracking |
| Update rate of deviation pixel | 30Hz |
| Output delay of deviation pixel | <3ms |
| Minimum object size | 32*32 pixel |
| Maximum object size | 128*128 pixel |
| Tracking speed | ±48 pixel/frame |
| Object memory time | 100 frames (4s) |
| Packing Information |
| N.W. | 490g (Viewport version) |
| Product meas. | 128.2*122*119mm / 128.2*122*143.5mm (Viewport version) |
| Accessories | 1pc gimbal camera device, screws, copper cylinders, damping balls, damping boards / Hight quality plastic box with foam cushion |
